4 1/2” RC550 METZKE RETENTION
At a Glance | |||
---|---|---|---|
Size
|
Shank
|
Air pressure
|
Air flow
|
|
DR55
|
250 - 500 psi
|
504 - 987 cfm
1360 - 2660 l/min |
Hammer Overview | ||||
---|---|---|---|---|
Hammer Model | 4½” RC550 METZKE RETENTION | |||
Part Number | 600804 | |||
Shank | DR55 | |||
Thread Connection | 4 ½" Metzke | |||
Weight | 179 lbs - 81kg | |||
Outside Diameter | ||||
Length (shoulder to shoulder) | 51” - 1294mm |
Parts List | Maintenance Kits | ||||
---|---|---|---|---|---|
Type | 4½” RC550 METZKE RETENTION | Service Kit | Repair Kit | ||
Shank | DR55 | ||||
Item | Description | Part No. | |||
1 | Circlip | 1107229 | No | No | |
2 | Adaptor Air Screen 4 ½” Metzke | 1059984 | No | No | |
3 | Top Sub 4 ½” Metzke | 1107234 | No | No | |
4 | Check Valve | 1048189 | No | No | |
5 | Check Valve Spring | 9001055 | No | No | |
6 | Adaptor Tube | 1048192 | No | No | |
7 | Steel Make Up Ring | 1009562 | No | No | |
8 | Make up Ring | 1010627 | No | No | |
9 | Distributor | 1048194 | No | No | |
10 | Sample Tube Venturi | 1048195 | No | No | |
11 | Sample Tube Mount | 1048196 | No | No | |
12 | Inner cylinder | 1048197 | No | No | |
13 | Piston | 1107238 | No | No | |
14 | Wear Sleeve | 1248977 | No | No | |
15 | Piston Retaining Ring | 1044582 | No | No | |
16 | Guide Bush | 1009572 | No | No | |
17 | Bit Retaining Ring | 1009573 | No | No | |
18 | Chuck Sleeve 5 7/16” Retention | 1051761 | No | No | |
19 | Chuck Retention | 1046868 | No | No |
